Affirm Breast Biopsy Guidance System Service Manual
Appendix E: Field Replaceable Units (FRUs)
Page 96 MAN-05754 Revision 002
Table 17: Recommended FRUs - Lateral Arm Assembly
Description
Part Number
Status / Notes
WHEEL, V-GUIDE, SHIELD .584BORE+.0/-
.00003X.1575BORE+/-
.002X.584ODX.250WIDE+.0/-.004, ST STL
MME-01543 Non-Returnable
BEARING,FLANGED 2-110-0063 Non-Returnable
Table 18: Recommended FRUs - Lateral Arm Carriage Assembly
Description
Part Number
Status / Notes
ASSY, CARRIAGE ASY-09247 Non-Returnable
CARRIAGE, LATERAL ARM RAIL FAB-13202 Non-Returnable
BLOCK, CARRIAGE T-SLOT FAB-13190 Non-Returnable
LEVER, CARRIAGE MOUNT RELEASE FAB-13134 Non-Returnable
MAGNET, 3/16DIA+/-.004X3/8+/-
.004THICK NEODYMIUM, PLATING NICKEL
MME-01734 Non-Returnable
Table 19: Recommended FRUs - Lateral Arm Removable X-axis Stop Assembly
Description
Part Number
Status / Notes
ASSY, REMOVABLE X-AXIS STOP ASY-09248 Non-Returnable
SHAFT, X-AXIS STOP FAB-13185 Non-Returnable
LEVER, X-AXIS STOP MOUNT RELEASE FAB-13188 Non-Returnable
BOSS, X-AXIS STOP CAM FAB-13181 Non-Returnable
POINTER, X-AXIS STOP, LH FAB-14246 Non-Returnable
POINTER, X-AXIS STOP, RH FAB-14247 Non-Returnable
Table 20: Recommended FRUs - Lateral Arm Needle Guide RH Assembly
Description
Part Number
Status / Notes
ASSY, NEEDLE GUIDE, RH ASY-09250 Non-Returnable
ARM, NEEDLE GUIDE MOUNT, RH FAB-13172 Non-Returnable
HOLDER, ALA NEEDLE GUIDE FAB-13174 Non-Returnable
Table 21: Recommended FRUs - Lateral Arm Needle Guide LH Assembly
Description
Part Number
Status / Notes
ASSY, NEEDLE GUIDE, LH ASY-09251 Non-Returnable
ARM, NEEDLE GUIDE MOUNT, LH FAB-13170 Non-Returnable
HOLDER, ALA NEEDLE GUIDE FAB-13174 Non-Returnable
