Affirm Breast Biopsy Guidance System Service Manual

Chapter 4: Calibration Procedures

Page 46 MAN-05754 Revision 002

Description


Part Number

Z-axis Calibration Tool

TLS-02432

Biopsy Device with Holder

Disposable Needle Guide (14-guage)

Lateral Arm Stand

ASY-09644

Lateral Arm Biopsy Paddle

ASY-05205

Lateral Arm QAS Phantom

ASY-09506

Lateral Arm Needle Guide Holder

(Blue), Left Approach

Lateral Arm Needle Guide Holder

(Gold), Right Approach

4.2 Front Needle Guide Alignment

This procedure ensures that the needle guide does not cause deflection of the needle

shaft as the needle guide mount is moved from needle base to tip.
