Affirm Breast Biopsy Guidance System Service Manual
Chapter 3: Installation, Verification, and Removal
Page 18 MAN-05754 Revision 002
Table 1: Components of the Biopsy Guidance Module
# Name Description
1 Attachment Hooks Two on each side hold the Biopsy Guidance Module on the
imaging system Gantry.
2 Handles One on each side. Hold both handles to lift the Biopsy Guidance
Module.
3 Biopsy Device
Advance/Retract
Knobs
Rotate either knob to move the biopsy device along the slide rail.
4 Slide Rail Holds the biopsy device mount and provides the track for manual
biopsy device movements.
5 Needle Guide Holder Holds the disposable needle guide through which the biopsy
needle is inserted. (This front needle guide is removed when the
Lateral Arm is installed.)
6 Device Mount Holds the biopsy device adapter to which the biopsy needle is
attached. Moves along the slide rail when a biopsy device
advance/retract knob is rotated.
7 Cable Connects to the imaging system to supply power to the Biopsy
Guidance Module.
8 Lock Lever One on each side. Engage the two levers to lock the Biopsy
Guidance Module in position and onto the C-arm.
9 Receptacle Accepts the cable from the Biopsy Control Module.
3.5 Biopsy Control Module Components
The Biopsy Control Module attaches to either the left or right handle on the Biopsy
Guidance Module with a bracket (item 5). The display screen (item 2) is a touch screen
