Faxitron CT Specimen Radiography System User Guide
Appendix A: System Specifications
5081-9544 Revision 004 Page 91
A.3.4 X-ray Tube Technical Information
Hologic P/N:
130-552025
Manufacturer P/N:
MF90150 (Oxford Instruments)
Max Anode Voltage
50 kV
Max Anode Current*
1.0 mA
Maximum Power
12W continuous (Isowatt limited to 11.5W max)
Focal Spot Size
<15 um
Anode Material / (Target)
Tungsten (W)
Cooling
Air cooled, 150 CFM at 100mm (4.0”) recommended
Beryllium Window Thickness
0.25mm (0.010”)
Window Material
Be 98.5%
Cone Angle
40.5 Degrees ±0.5°
Maximum Operating Temperature
50°C (at potting surface)
Ambient Operating Conditions
0°C to 40°C; 0-95% RH up to 5,000ft
Weight
3 lbs
Storage Temperature Range
-10°C - 55°C
Storage Humidity Range
10-90% (no condensation)
A.3.5 Computer Specifications
This table provides minimum recommended specifications at time of publication.
Hologic P/N: 2001-0031
Processor
Intel
®
Core
TM
i7-7700 (4 Cores)
Operating System
Windows 10 Enterprise LTSC (64 bit)
System RAM
32 GB, DDR4, 2666MHz
Hard Drive
3.5-inch 4TB 7200rpm SATA
2.5-inch 480GB SATA MLC/TC
Optical Drive
DVD-RW SATA
Network Connectivity
Integrated Intel
®
i219LM Ethernet + Intel
®
i21AT LAN
10/100/1000
USB Ports
FRONT Panel
USB 2.0 – 2X
REAR Panel
USB 2.0 – 2X
USB 3.0 – 4X
Graphics Card
GeForce
®
RTX 2080 Ti 11GB GDDR6 Memory
Or NVIDIA Quadro RTX5000 16GB GDDR6 Memory
Case/Chassis
4U Rack Mount
Dimensions (H x W x D)
6.9” x 16.8” x 16.1” (17.5cm x 42.7cm x 40.9cm)
Min. Weight
34.8 lbs (15.8 kg)
Monitor
24”
2560 x 1440 (3.7MPX) Native Resolutions
1000:1 Contrast Ratio
300 cd/m^2 Brightness
Display Port Input
