Faxitron CT Specimen Radiography System User Guide
Chapter 5: Calibration
5081-9544 Revision 004 Page 43
Uniformity Calibration utilizes a clear Uniformity Calibration Phantom. The bottom of
the phantom has a flat cut into it which matches the recess in the CT pedestal. This recess
ensures the phantom is properly positioned and prevents it from shifting during
calibration.
Place the Uniformity Calibration Phantom on the pedestal then click the Okay button in
the dialog. The Start Uniformity Calibration Dialog will open.
Figure 39: Image Display Screen
Check the box to confirm the Phantom is placed then click the Start button.
The calibration will begin taking a full 360-degree image of the phantom which takes up
to 4 minutes.
