Honeywell C300 User Manual

3. C300 Controller Installation and Upgrades
3.2. C300 Controller installation
34
Series 8 C300 Controller User's Guide
Honeywell
R500
April 2017
C300 IOTA Board
Description
FTE A, FTE B
Fault Tolerant Ethernet (FTE) network
connectors
FTE A network cable connectors are Yellow.
FTE B network cable connectors are Green.
REDUNDANCY
Redundant private path cable connector.
Redundancy cable connector is Orange
MEMORY HOLD-UP
Battery Backup cable connector
Battery cable is a twisted pair.
GPS (Currently not used)
GPS cable connector
FTE DEVICE INDEX
99, 10, 1
Three rotary decimal switches used to set the
FTE network address (Device Index) of the
controller.
Refer to the C300 Controller Installation
procedure for setting the address.
Prerequisites
Before you install the C300 Controller you should have:
 A control cabinet installed with panel for mounting Series 8 control hardware.
 A Series 8 power supply and optional battery backup hardware installed in the
cabinet.
 Following are the parts included:
 C300 Controller assembly (control module with IOTA board and mounting
hardware)
 2 STP Cat5 Ethernet cables (one Yellow cable, one Green cable)
 2 or 4 IOLink cable assemblies for connecting on-board IO Link interface if the
controller is supporting Series 8 I/O
 Ensure the cabinet enclosure is connected to a protective earth ground using #8 AWG
solid copper wire. There should be metal to metal contact between the grounding bus
bar and the enclosure as well as the channel.

Honeywell C300 Specifications

General

Memory	512 MB RAM, 512 MB Flash
Type	Process Controller
Communication Ports	Ethernet, Serial
Power Supply	24V DC
Inputs	Analog and Digital
Outputs	Analog and Digital
Communication	Ethernet, Serial, HART
Redundancy	Supported (Hot Standby)
