4. C300 Controller Configuration
4.13. Assign I/O Modules to C300 IOLINK blocks
R500
April 2017
Series 8 C300 Controller User's Guide
Honeywell
81
To assign Series 8 IO Modules to IOLINK blocks, perform the following steps.
Step
Action
Result
1
Click Edit > Execution Environment
Assignment. Or, click assignment
button in the toolbar.
The Execution Environment Assignment
dialog box appears. (There is no set
default state for the dialog, so it may
appear with different active fields than
shown below.)
TIP
You can use common <Shift> plus click and <Control> plus click actions to select
multiple items in Available Modules and Assigned Modules lists.
