Series 8 C300 Controller User's Guide
Honeywell
R500
April 2017
5. C300 Configuration Form Reference
5.1. C300 Controller Block
Plain Text
Parameter Name
User
Configurable
Notes
Tag Name
Tag Name
Project Only
System assigned or user
configured unique name.
Consisting of up to 16
characters and at least
one character must be a
letter (A-Z).
Item Name
Item Name
Project Only
A non-unique name by
which an entity is known
within the context of the
enterprise model.
Application Image
Version
IMAGEVER
No
Identifies current version
of application firmware
installed in module.
Controller Command
C300COMMAND
Monitoring
Only
Allows user to initiate
commands to a C300
Controller.
Network Address Configuration
Device Index
DEVICEIDX
Project Only -
Matches
Hardware
Setting
Unique FTE Device Index
of the C300 Controller.
Set on the C300 IOTA
switches.
Ethernet IP Address
IPADDRESS
No
IP address of the C300
Controller, derived as the
Embedded FTE Base
Ethernet IP Address and
the configured Device
Index.
State Information
Controller State
C300STATE
No
Shows C300 Controller's
current module state.
Redundancy Role
RDNROLESTATE
No
Shows C300 Controller's
current redundancy role.

Honeywell C300 Specifications

General

Memory	512 MB RAM, 512 MB Flash
Type	Process Controller
Communication Ports	Ethernet, Serial
Power Supply	24V DC
Inputs	Analog and Digital
Outputs	Analog and Digital
Communication	Ethernet, Serial, HART
Redundancy	Supported (Hot Standby)
