GX-Series Control Panel Installation and Setup Guide
6-55
No Event text Description Alarm Closed Omit Unomit Troub Tr. Res Test Tamp
1 Default
2 AT/R Power AC Trouble, AC Restoral AT AR BB BU BT BJ BX TA
3 BA/R Burglary Burglary Alarm, Burglary Restoral BA BR BB BU BT BJ BX TA
4 DG/D Access Access Granted, Access Denied DG DD BB BU DT DJ BX TA
5 FA/R Fire Fire Alarm, Fire Restoral FA FR FB FU FT FJ FX TA
6 GA/R Gas Gas Alarm, Gas Restoral GA GR GB GU GT GJ GX TA
7 HA/R Holdup Holdup Alarm, Holdup Restoral HA HR HB HU HT HJ BX TA
8 KA/R Heat Heat Alarm, Heat Restoral KA KR KB KU KT KJ BX TA
9 LT/R Line Fail Line Trouble, Line Restoral LT LR BB BU BT BJ BX TA
10 MA/R Medical Medical Alarm, Medical Restoral MA MR MB MU MT MJ BX TA
11 PA/R Panic Panic Alarm, Panic Restoral PA PR PB PU PT PJ BX TA
12 QA/R Assist Emergency Alarm, Emergency Restoral QA QR QB QU QT QJ BX TA
13 RO/C Relay Relay Open, Relay Closed RO RC BB BU BT BJ BX TA
14 SA/R Sprinklr Sprinkler Alarm, Sprinkler Restoral SA SR SB SU ST SJ BX TA
15 TA/R Tamper Tamper Alarm, Tamper Restoral TA TR TB TU BT BJ TX TA
16 WA/R Water Water Alarm, Water Restoral WA WR WB WU WT WJ BX TA
17 YT/R Battery Battery Alarm, Battery Restoral YT YR BB BU BT BJ BX TA
18 ZA/R Freezer Freezer Alarm, Freezer Restoral ZA ZR ZB ZU ZT ZJ BX TA
Table 6-14. Customizable Mnemonics
NOTE: If two zones, programmed as Custom SIA, activate within the confirm time window, whether it be in the
SET (ARMED) or UNSET (DISARMED) condition, then a CONFIRM is logged.
8 = Activity Mon.
This attribute allows a zone to be checked for activity during a set (armed) time period or set/unset
(arm/disarm) cycles. The options are:
0 = None
1 = Type1
2 = Type2
3 = Type3
4 = Type4
5 = Type5
6 = Type6
The default option is 0 = None.
If the zone does not activate at least once within the programmed criteria a zone masked fault is indicated at
the panel. The fault is logged as a masked event which indicates that the zone has been inactive for the
programmed period. See Option 51.61=Parameters.Activity Monitoring.
9 = Res. Select
This option allows the zone resistor configuration to be selected from a pre-defined value.
00 = System (follows the system default as programmed in parameter 51.46 = Zone Resistance)
Option 01 = Preset 1 - 1k (double balanced)
Option 02 = Preset 1 - 1k (end-of-line)
Option 03 = Preset 2 – 2.2k (double balanced)
Option 04 = Preset 2 – 2.2k (end-of-line)
Option 05 = Preset 3 – 4.7k (double balanced)
Option 06 = Preset 3 – 4.7k (end-of-line)
Option 07 = Preset 4 – 5.6k (double balanced)
Option 08 = Preset 4 – 5.6k (end-of-line)
Option 09 = 1k Fault (double balanced)
Option 10 = 1k Fault (end-of-line)
The values assigned by each of the options are shown in tables 10 and 11, Parameter 51.46=Zone Resistance.
