GX-Series Control Panel Installation and Setup Guide
6-56
10 = Group
NOTE: The Groups attribute is only available if groups have been enabled on the system (refer to option 63 =
OPTIONS).
The Group attribute allows the zone to be assigned to a single group on the system. All zones default to
Group A1.
On selecting the Group attribute, the group that the zone is currently assigned to is displayed. All zones
default to group A1. Press the number of the group that the zone is to be reassigned to and press the ent
key.
Multi-group Systems
The larger GX-Series panels have 32 groups; these are displayed on the keypad in blocks of eight groups,
subdivided into A, B, C and D.
Use the A> or <B key to select the required group (A1–D8). When the end of a block is reached, the next
block of eight groups is displayed; use keys 1–8 to assign the relevant group in the current block to the zone;
press the ent key to accept the selection.
Star (*) Group Function
Certain zone functions have an additional Group attribute feature that allows the other groups to be
affected by their operation. This feature is assigned by pressing the * key when allocating the group to the
zone.
On pressing the * key the display indicates the group currently assigned to the zone and prompts for other
groups to be added, for example 1* 1 – – – – – – –, pressing 4 and 7 assigns 1 * 1 – – 4 – – 7 –.
Final, Secure Final, Part Final Keyswitch and Push Set Zones
If the star * group feature is assigned a zone programmed as Final, Secure Final, Part Final or Push
Set, then closing the zone when setting (arming) multiple groups terminates the setting (arming) procedure
for all groups assigned to the zone.
Refer to the zone functions for further information on the operation of these zone functions.
Exit Zones
The star T group feature can be assigned to a zone programmed as Exit. This allows an Exit zone to be
activated in a group which is not currently being unset (disarmed) without activating an Intruder alarm
condition.
Refer to the zone functions for further information on the operation of this zone function.
System Alarms
The GX-Series panels have tamper and alarm monitoring circuits which are not programmable. These
circuits maintain the integrity of the system and all correspond to Group A1.
Zone Alarm Description
0001 CUBATT Control unit battery low
0002 CUAC Control unit AC fail
0003 LID TAMPER Control unit lid tamper
0004 AUX TAMPER Control unit tamper return
Table 6-15. Control Panel Alarms
