GX-Series Control Panel Installation and Setup Guide
D-2
KEYPAD TEXT DESCRIPTION
TRIGGER
EVENT
DL/SL ALM PA Delayed Silent zone activated after PA Delay timeout. 1. PA/duress M
DOOR PROP MAX - Door left open 4. Security NM
DR MASKED Detector Masked. Activity Monitoring of zone has failed. 15. Trouble
20. Fault
DUAL Dual (Double Knock) zone activated (opened). 2. Intruder M
DURESS Duress code has been entered 1. PA/Duress M
ENG ASSEM Engineering Assemble Zone Menu (Menu Option 64) has been accessed. 14. Menu Access M
ENG CHECK Engineering Pre-Check Menu (Menu Option 66) has been accessed. 14. Menu Access M
ENG DIAG Engineering Diagnostics Menu (Menu Option 61) has been accessed. 14. Menu Access M
ENG DIGI Engineering Digicom (Communications) (Menu Option 56) has been accessed. 14. Menu Access M
ENG GROUP Engineering Groups (Menu Option 63) has been accessed. 14. Menu Access M
ENG KPAD Engineering Keypad (Menu Option 58) has been accessed. 14. Menu Access M
ENG LINKS Engineering Links (Menu Option 54) has been accessed. 14. Menu Access M
ENG O/PS Engineering Outputs (Menu Option 53) has been accessed. 14. Menu Access M
ENG PARAM Engineering Parameters (Menu Option 51) has been accessed. 14. Menu Access M
ENG PRINT Engineering Print (Menu Option 57) has been accessed. 14. Menu Access M
ENG QUICK Engineering Quick Menu (Menu Option 59) has been accessed. 14. Menu Access M
ENG SOAK Engineering Soak Test (Menu Option 55) has been accessed 14. Menu Access M
ENG TEST Engineer Test of the system via the Telecom Module. Always TR NM
ENG TMRS Engineering Timers A/B (Menu Option 65) has been accessed. 14. Menu Access M
ENG ZONES Engineering Zones (Menu Option 52) has been accessed. 14. Menu Access M
ENG TAMP Tamper when entering Engineer Mode. None NM
+ENGINEER Entering Engineer Mode. Always TR NM
–ENGINEER Leaving Engineer Mode. Always TR NM
ENT DELAY User entering Ent Delay State None NM
ENT SET User entering Ent Set State None NM
ENT SETNG User entering Setting State None NM
ENT UNSET User entering Unset State None NM
ENT UNST User entering Unsetting (disarming) State None NM
+ENTRY Entry zone activated (opened) during Setting/Unsetting (arming/disarming)
procedure or when Set.
None NM
–ENTRY Entry zone de-activated (closed) during Setting/Unsetting (arming/disarming)
procedure or when Set.
None NM
ETST FAIL Engineer test has failed None NM
ETST PASS Engineer test has passed None NM
+EXIT Exit zone activated (opened) during the Unsetting (disarming) procedure or
when Set.
2. Intruder NM
–EXIT Exit zone de-activated (closed) during the Unsetting (disarming) procedure or
when Set.
2. Intruder NM
EXITGUARD ExitGuard zone activated (opened). 16. Log NM
EXTENSION System or Group(s) are in the Autoset Extension period. 10. Setting NM
FAIL SET Fail to set event. 7. Set Fault M
+FAULT Fault condition activated on zone 20. Fault M
–FAULT Fault condition cleared from zone 20. Fault M
FAULT RST Fault has been cleared 20. Fault NM
FB BAT LOW RF Fob has low battery None NM
+FINAL Finalzone activated (opened) during Setting/Unsetting (arming/disarming)
procedure or when Set.
7. Set Fault NM
–FINAL Final zone de-activated (closed) during Setting/Unsetting (arming/disarming)
procedure or when Set.
7. Set Fault NM
FIRE Fire zone activated (opened). 6. Fire M
FOB REJCT Illegal fob None M
FORCE OMT Force Omit of a zone (Menu Option 14). 8. Omit M
FULL SET Full Set (Menu Option 12) of the system or Group(s). 10. Setting M
FULL TEST Full Test (Menu Option 62) has occurred. None NM
FUSE 14.5
◊
Fault with 14.5V protection on Power Supply Unit 13. Elec. Status
20. Fault
M
FUSE AUX1
◊
Fault with AUX1 protection on Power Supply Unit 9. Tamper
13. Elec. Fault
M
FUSE AUX2
◊
Fault with AUX2 protection on Power Supply Unit 9. Tamper
13. Elec. Status
M
FUSE BELL
◊
Change fuse to protection. 9. Tamper
13. Elec. Status
M
+GRP OMIT Area bypass has occurred (Group(s) has been omitted). 8. Omit M
–GRP OMIT Group omit/area bypass has finished (Group(s) has been un-omitted). 8. Omit M
+HIGH RES Zone changing to High Resistance (1200 to 1300 Ohm) Engineer Log only. 15. Trouble M
◊
The PC board uses a PTC device instead of a fuse. The PTC serves as an automatically resetting fuse.
