Honeywell UDC2300 - Table 9-4 Auxiliary Output Calibration Procedure (Numeric Code 50000)

Troubleshooting/Service
12/00 UDC2300 Controller Product Manual 99
Procedure
The procedure for calibrating the auxiliary output is listed in Table 9-4. The numeric
codes are also listed.
Make sure “LOCK” in the Tuning Set Up group is set to “NONE” (see Subsection 4.5).
Table 9-4 Auxiliary Output Calibration Procedure
(Numeric Code 50000)
Step Operation Press Result
1
Enter Calibration
Mode
SET UP
until you see
Upper Display = CAL (
- - - - )
Lower Display = AUXOUT (50000)
2
Calibrate 0 %
FUNCTION
You will see:
Upper Display = A Value
Lower Display = ZROVAL (50001)
[▲] [▼] until the desired 0 % output is read on the milliammeter, use
the values shown below depending on the action of your
controller.
3
Calibrate 100 %
FUNCTION
To store the 0 % value you will see:
Upper Display = A Value
Lower Display = SPNVAL (50002)
[▲] [▼] until the desired 100 % output is read on the milliammeter.
4
FUNCTION
The controller stores the span value.Exit the
Calibration Mode
DISPLAY
To exit the calibration mode.
