Honeywell UDC2300 User Manual

Installation
12/00 UDC2300 Controller Product Manual 7
Jumper Placements
W201
NO
NC
Alarm Relay #1
NC (default)
NO
NC
NO
W202
NO
NC
Output #2/
Alarm Relay #2
NC (default)
NO
NC
NO
W101
NO
NC
Output #1
NC
NO
NC
NO (Default)
S101
4 3 2
1
Input #1
Position 1: thermocouple (default)
Position 2: mV, Volt, RTD
Position 3: not used
Position 4:
mA
No jumper: 0 -10 volts
Note: Jumpers enlarged for clarity
S201
W201
2 1
W202
NO
NC
NO
NC
S101
4 3 2
1
W101
NO
NC
Input #2
2 1
2
1
Volt
mA
Jumper
Position 2
S201
Jumper
Position 1
Main
Board
1
1. For Current Output use the N.O. position
Figure 2-2 Jumper Placements
