Configuration
12/00 UDC2300 Controller Product Manual 29
4.6 SP Ramp Set Up Group
Introduction
A single setpoint ramp [SPRAMP] can be configured to occur between the current local
setpoint and a final local setpoint over a time interval of from 1 to 255 minutes.
SPRATE lets you configure a specific rate of change for any local setpoint change.
You can also configure a 12-segment program from a Ramp/Soak profile.
You can start and stop the ramp/program using the RUN/HOLD key.
PV Hot Start is standard and means that at power up, the setpoint is set to the current PV
value and the Ramp or Rate or Program then starts from this value.
Function Prompts
Table 4-5 SPRAMP Group (Numeric Code 300) Function Prompts
Prompt Selection or Range of Setting
English Numeric
Code
Description
Numeric
Code
English
Factory
Setting
Reference
Guide
Page
SP RAMP 301
Single Setpoint
Ramp
0
1
DIS
ENAB
Rate and Program must
be disabled
DIS 154
TI MIN 302
Single Setpoint
Ramp Time
0 to 255 minutes 3 156
FINLSP 303
Setpoint Ramp
Final Setpoint
Enter a value within the
setpoint limits
1000 134
SPRATE 304
Setpoint Rate 0
1
DIS
ENAB
Ramp and Program must
be disabled
DIS 154
EUHRUP 305
Rate Up 0 to 9999 in Engineering
units per hour
0 133
EUHRDN 306
Rate Down 0 to 9999 in Engineering
units per hour
0 133
SPPROG 307
Setpoint
Ramp/Soak
Programming
0
1
DIS
ENAB
Rate and Ramp must be
disabled
DIS 154
STRSEG 308
Start Segment
Number
1 to 11 - - - 156
ENDSEG 309
End Segment
Number
2
4
6
8
10
12
2 to 12 (always end in a
soak segment 2, 4, … 12)
SOK 2
SOK 4
SOK 6
SOK 8
SOK 10
SOK 12
- - - 133
