Configuration

12/00 UDC2300 Controller Product Manual 31

4.7 Accutune Set Up Group

Introduction

Accutune II automatically calculates GAIN, RATE, and RESET TIME (PID) tuning

constants for your control loop. When initiated on demand, the Accutune algorithm

measures a process step response and automatically generates the PID tuning constants

needed for no overshoot on your process.

Fuzzy Overshoot Suppression, when enabled, will suppress or eliminate any overshoot

that may occur as a result of the existing tuning parameters, as the PV approaches the

setpoint.

Function Prompts

Table 4-6 ATUNE Group (Numeric Code 400) Function Prompts

Prompt Selection or Range of Setting

English Numeric

Code

Description

Numeric

Code

English

Factory

Setting

Reference

Guide

Page

FUZZY 401

Fuzzy Overshoot

Suppression

DIS

ENAB

DIS 135

TUNE 402

Demand Tuning 0

DIS

TUNE

TUNE 157

AT ERR 403

Accutune Error

Codes (Read Only)

NONE

IDFL

ABRT

RUN

- - - 121
