Operation
12/00 UDC2300 Controller Product Manual 65
Table 6-11 Set Up Procedure
Step Operation Press Result
1
Select Control
Set-up Group
SET UP
Until you see:
Upper Display = SET
Lower Display = CONTRL
2
Select PID SETS
FUNCTION
Until you see:
Upper Display = (available selections)
Lower Display = PID SETS
3
Select PID SETS
Function
[▲] [▼] To select the type of function. Available selections are:
ONE—1 set of constants
2 KBD—2 sets, keyboard selectable
2 PR—2 sets, auto switch at PV value
2 SP—2 sets, auto switch at SP value
4
Set Tuning
Values for Each
Set
Refer to “TUNING” Set up group, subsection 4.5 and set the
following tuning parameters:
PB or GAIN*
RATE T*
I MIN or I RPM*
CYCT1 or CTIX3*
PB2 or GAIN2**
RATE 2T**
I2MIN or I2RPM**
CYC2T2 or CT2X3**
*PIDSET1 will be used when PV or SP, whichever is
selected, is greater than the switchover value.
**PIDSET2 will be used when PV or SP, whichever is
selected, is less than the switchover value.
5
Set Switchover
Value for 2PR or
2SP Selection
FUNCTION
Until you see:
Upper Display = (the switchover value)
Lower Display = SW VAL
[▲] [▼] To select the switchover value in the upper display.
Switch between two sets via keyboard (without automatic switch-over)
Table 6-12 Procedure for Switching PID SETS from the Keyboard
Step Operation Press Result
1
Select Control
Set-up Group
DISPLAY
Until you see:
Upper Display = (the PV value)
Lower Display = PIDS X (X= 1 or 2)
2
[▲] [▼]
To change PID SET 1 to PID SET2 or Vice Versa.
You can use Accutune on each set.
