Installation
4 UDC2300 Controller Product Manual 12/00
Pre-installation Information
If the controller has not been removed from its shipping carton, inspect the carton for
damage then remove the controller.
• Inspect the unit for any obvious shipping damage and report any damage due to transit
to the carrier.
• Make sure a bag containing mounting hardware is included in the carton with the
controller.
• Check that the model number shown on the inside of the case agrees with what you
have ordered.
Condensed Specifications
We recommend that you review and adhere to the operating limits listed in Table 2-1
when you install your controller.
Table 2-1 Condensed Specifications
Operating Limits Ambient Temperature: 32 °F to 131 °F (0 °C to 55 °C)
Relative Humidity: 5 % to 90 % RH up to 104 °F (40 °C)
Vibration:
Frequency: 0 to 200 Hz
Acceleration: 0.6g
Mechanical Shock:
Acceleration: 5g
Duration: 30 ms
Power:
90 Vac to 264 Vac, 50/60 Hz
(CSA models rated to 250 Vac maximum)
Power Consumption: 12 VA maximum
Accuracy
± 0.25 % of span typical
± 1 digit for display
15-bit resolution typical
CE Conformity Special
Conditions (Europe)
Shielded twisted-pair cables are required for all analog I/O,
process variable, RTD, thermocouple, dc millivolt, low level
signal, 4-20 mA, digital I/O, and computer interface circuits.
