12/00 UDC2300 Controller Product Manual 159
12.2.110 XMITR2 (TRANSMITTER CHARACTERIZATION)
This prompt is part of the Input 2 Set up group.
This selection lets you instruct the controller to characterize a linear input to represent a
non-linear one.
ATTENTION
Prompt only appears when a linear actuation is selected at prompt IN2TYP.
FOR EXAMPLE:
If input 2 is a 4 to 20 mA signal, but the signal represents a type K thermocouple, select K H and
the controller will characterize the 4 to 20 mA signal so that it is treated as a type K thermocouple
input (high range).
Selections Definitions
B
E H
E L
J H
J L
K H
K L
NNMH
NNML
N90H
N90L
NIC
R
S
T H
T L
W H
W L
100H
100L
200
500
RADH
RADI
LIN
SrT
B—B Thermocouple
E H—E Thermocouple High
E L—E Thermocouple Low
J H—J Thermocouple High
J L—J Thermocouple Low
K H—K Thermocouple High
K L—K Thermocouple Low
NNMH—Ni-Ni-Moly Thermocouple High
NNML—Ni-Ni-Moly Thermocouple Low
N90H—NiMo-NiCo Thermocouple High
N90L—NiMo-NiCo Thermocouple Low
NIC—Nicrosil-Nisil Thermocouple
R—R Thermocouple
S—S Thermocouple
T H—T Thermocouple High
T L—T Thermocouple Low
W H—W5W26 Thermocouple High
W L—W5W26 Thermocouple Low
100H—100 Ohm RTD High
100L—100 Ohm RTD Low
200—200 Ohm RTD
500—500 Ohm RTD
RADH—Radiamatic RH
RADI—Radiamatic RI
LIN—Linear
SrT—Square Root
