Configuration
12/00 UDC2300 Controller Product Manual 37
Table 4-10 CONTRL Group (Numeric Code 800) Function Prompts, continued
Prompt Selection or Range of Setting
English Numeric
Code
Description
Numeric
Code
English
Factory
Setting
Reference
Guide
Page
OUT Hi 811
High Output Limit -5 to 105 % of Output
(Current)
0.0 to 100.0 % of Output
(Relay)
100 143
OUT Lo 812
Low Output Limit -5 to 105 % of Output
(Current)
0.0 to 100.0 % of Output
(Relay)
0 143
D BAND 813
Deadband -5 to 25.0 % (Time Duplex)
0.5 to 5.0 % (3 position
step)
2.0 130
HYST 814
Hysteresis (Output
Relay Only)
0.0 to 100.0 % of PV 0.5 135
FAILSF 815
816
Failsafe Output
Value
0
1
0 to 100 %
For 3 Position Step
0 (Closed position)
100 (Open position)
0.0 134
FSMODE 817
Failsafe Mode 0
1
No L (Mode does not clear
once unit goes to FS
Output)
LACH (Unit goes to manual
and FS output)
NO_L 135
PBorGN 818
Proportional Band
Units
0
1
GAIN
PB
GAIN 145
MINRPM 819
Reset Units 0
1
MIN
RPM
MIN 142
To Next Page
