HP Integrity rx4640 Service Guide

PCI Bus, PCI Device, and PCI Function to the Bus #, Dev #, and Fnc # values from
the info io command.
CAUTION: Do not change the value for any of these following fields on the “Adapter
Properties” screen:
• Auto Termination
• SCSI Parity
• SCSI Bus Scan Order
• Spinup Delay (Secs)
Changing any of these fields can cause unpredictable results.
CAUTION: Do not change the value for any of these following fields on the “Device
Properties” screen:
• Scan Id
• Scan LUNs > 0
• Disconnect
• SCSI Timeout
• Queue Tags
• Format
• Verify
Changing any of these fields can cause unpredictable results.
9. You can display (and optionally change) any SCSI parameters listed below for the channel
of the SCSI interface, or restore its SCSI parameters to their default values.
• SCSI ID
• Maximum data transfer rate
• Bus width
• Whether the SCSI interface is bootable (driver support)
• Avoid bus resets (secondary cluster server)
• Restore Defaults
10. To navigate to the appropriate SCSI parameter, use the arrow keys.
11. To scroll through the values, use the plus (+) and minus (-) keys.
12. To exit the Adapter Properties screen, press Esc. You are given these choices:
• Cancel the exit from the screen (to stay in the Adapter Properties screen for the channel
of the SCSI interface)
• Save the changes you made and exit the screen
• Discard the changes you made and exit the screen
13. Move the cursor to the action (cancel, save, or discard) you want to take; press Enter.
If you selected cancel, you remain in the Adapter Properties screen for the channel of the
SCSI interface. You can still change the channel’s parameters listed above.
If you selected save or discard, you are placed in the EFI SCSI Setup Utility’s main menu.
CAUTION: Do not select the <Global Properties> option on the main menu.
14. To exit the main menu and the EFI SCSI Setup Utility, press Esc.
15. Select the option for exiting the utility.
16. When you are prompted, press Enter to stop the SCSI interface; you are now back at the
EFI shell prompt.
17. At the EFI shell prompt, enter reset.
The server starts to reboot. This is required to cause the new SCSI setting.
156 Utilities
