Replacing the DVD Drive
To replace a DVD drive, follow these steps:
1. Push the drive straight into the drive bay until the locking tab clicks into place. Figure 4-42
shows how to replace the DVD drive.
2. Replace the front bezel. See “Replacing the Front Bezel” (page 34).
Removing and Replacing the DVD I/O Board
The DVD I/O board is located under a metal cover that is directly under DVD location at the
front left of the chassis.
WARNING! Ensure that the server is powered off and all power sources have been disconnected
from the server prior to removing or replacing a DVD I/O board.
Voltages are present at various locations within the server whenever an AC power source is
connected. This voltage is present even when the main power switch is in the off position.
Failure to observe this warning can result in personal injury or damage to equipment.
CAUTION: Failure to properly complete the steps in this procedure results in erratic server
behavior or server failure. For assistance with this procedure contact your local HP Authorized
Service Provider.
Observe all ESD safety precautions before attempting this procedure. Failure to follow ESD safety
precautions can result in damage to the server.
Removing the DVD I/O Board
To remove the DVD I/O board, follow these steps:
1. If rack mounted, slide the server out from the rack until it stops. See “Extending the Server
From the Rack” (page 31).
2. Remove the front bezel. See “Removing the Front Bezel” (page 34).
3. Remove the front cover. See “Removing the Front Cover” (page 35).
4. Remove the top cover. See “Removing the Top Cover” (page 36).
5. Remove the memory extender board. See “Removing the Memory Extender Board” (page 37).
6. Remove the processor extender board. See “Removing the Processor Extender Board”
(page 43).
7. Using a torx #15 driver, remove the two torx screws holding the DVD I/O board cover plate
to the chassis and remove the cover plate.
88 Removing and Replacing Components
