7. If rack mounted, slide the server back into the rack until it stops. See “Inserting the Server
into the Rack” (page 32).
Removing and Replacing the DVD Drive
These procedures show how to remove and replace the DVD drive. The DVD drive is located
on the front of the HP server.
WARNING! Ensure that the server is powered off and all power sources have been disconnected
from the server prior to removing or replacing a DVD drive.
Voltages are present at various locations within the server whenever an AC power source is
connected. This voltage is present even when the main power switch is in the off position.
Failure to observe this warning can result in personal injury or damage to equipment.
CAUTION: Failure to properly complete the steps in this procedure will result in erratic server
behavior or server failure. For assistance with this procedure contact your local HP Authorized
Service Provider.
Observe all ESD safety precautions before attempting this procedure. Failure to follow ESD safety
precautions can result in damage to the server.
Removing the DVD Drive
To remove the DVD drive, follow these steps:
1. To release the drive, grasp the front of the DVD drive, and squeeze in on the locking tab.
2. Remove the front bezel. See “Removing the Front Bezel” (page 34).
3. Pull the drive straight out to remove it from the chassis. Figure 4-42 shows how to remove
the DVD drive.
Figure 4-42 Removing and Replacing the DVD Drive
Removing and Replacing the DVD Drive 87
