6. Replace the top cover. See “Replacing the Top Cover” (page 36).
7. Replace the front cover. See “Replacing the Front Cover” (page 35).
8. Replace the front bezel. See “Replacing the Front Bezel” (page 34).
9. If rack mounted, slide the server into the rack until it stops. See “Inserting the Server into
the Rack” (page 32).
Removing and Replacing the Display Board
These procedures detail how to remove and replace the display board. The display board is
located behind the control panel and under the front cover. The display board contains the
server’s on/off switch and three LEDs that indicate server status.
WARNING! Ensure that the server is powered off and all power sources have been disconnected
from the server prior to removing or replacing the display board.
Voltages are present at various locations within the server whenever an AC power source is
connected. This voltage is present even when the main power switch is in the off position.
Failure to observe this warning can result in personal injury or damage to equipment.
CAUTION: Failure to properly complete the steps in this procedure will result in erratic server
behavior or server failure. For assistance with this procedure, contact your local HP Authorized
Service Provider.
Observe all ESD safety precautions before attempting this procedure. Failure to follow ESD safety
precautions can result in damage to the server.
Removing the Display Board
To remove the display board, follow these steps:
1. If rack mounted, slide the server out from the rack until it stops. See “Extending the Server
From the Rack” (page 31).
2. Remove the front bezel. See “Removing the Front Bezel” (page 34).
3. Remove the front cover. See “Removing the Front Cover” (page 35).
4. Using your finger, slightly pull out the retaining tab on the chassis that holds the display
board in position.
5. Gently unplug the midplane riser board connector cable from the display board and remove
the board from the chassis. Figure 4-44 shows how to remove the display board.
90 Removing and Replacing Components
