HP Integrity rx4640 Service Guide

* indicates a currently selected device.
This menu is identical to Console Error Devices. The HP Integrity rx4640 server does not support
different configurations for Output and Error console. For correct operation:
• When changes are made to either Output or Error console menus, the identical change must
be made in both menus.
• When changing serial devices, changes must be made to Output, Input, and Error menus
for proper operation.
Table C-5 Console Output Devices
Choose:To select:
Acpi(PNP0501,0)/Uart(9600 N81)/VenMsg(Vt100+)Serial A/Serial 1
Acpi(HWP0002,700)/Pci(1|1)/Uart(9600 N81)/VenMsg(Vt100+)iLO MP Serial Console
Acpi(HWP0002,700)/Pci(2|0)iLO MP VGA Port
• Each option is identified with an EFI device path. Not all options will be available, depending
on the configuration of the server and the options purchased. Device paths can differ slightly
on different product models.
• On both serial device examples, UART 9600 indicates the current baud rate of the serial
device (can be changed with the EFI shell baud command), VenMsg Vt100+ is the current
emulation type (several different terminal emulation protocols are supported, see list above).
• Only one terminal emulation type (PcAnsi, Vt100, etc.) can be selected for each serial console,
but multiple serial consoles can be selected at a time.
Using the System Configuration Menu
The System Configuration Menu (on servers with EFI firmware version 2.0 or higher) includes
the following options:
• Advanced System Information
• Set System Time
• Set System Date
• Set User Interface
• Set System Wake-On LAN
• Set System Defaults
Advanced System Information
The Advanced System Information Menu displays information about server and component
configuration.
Set System Time
Set System Time lets you modify the system time.
Set System Date
Set System Date lets you modify the system date.
Set User Interface
Set User Interface lets you change the legacy boot manager user interface.
Set System Wake-On LAN
Set System Wake-On LAN lets the user enable or disable the server Wake-On_LAN settings.
Set System Defaults
Set System Defaults lets you select system default settings.
162 Utilities
