HP Z600

4. Push the expansion card retention clamp levers down on the outside of the chassis to release the
clamp as shown in the following figure
.
Figure 5-80 Removing the slot cover
5. Lift the slot cover straight up to remove it from the chassis
2
.
TIP: Grasp the slot cover between two fingers—one from the inside of the chassis, and one from
the outside.
ENWW Removing and installing components 137
