Component Server
Management ports One serial port, four USB 2.0 ports, one 1G/100/10 LAN port, and two VGA ports
NOTE:
The serial port is intended primarily for use as a serial console port. It can be
configured through iLO 3 for use with other serial devices (subject to OS and
device limitations and dependencies). The serial port reverts to console
mode settings if the server is disconnected from AC power or if the iLO is
reset by the iLO Physical Presence button.
Optical drive
One SATA DVD+RW drive
Power supply One (AH395A) or two power supplies (AH396A) are standard. Supplies are dual
range input: 100-120VAC & 200-240VAC capable. 1+1 redundancy is possible with
the second supply.
IMPORTANT:
100-120 VAC input limits configuration and redundancy options. For details,
see Removing and replacing a hot-swap power supply on page 146.
Server subsystems
12 Server subsystems
