To replace the component, see Installing expansion boards on page 62.
Removing and replacing a full-length expansion board
Procedure
1. Power off the server (Powering off the server on page 138).
2. Extend the server from the rack (Extending the server from the rack on page 134).
3. Remove the access panel (Removing and replacing the access panel).
4. Disconnect any external cables that are connected to the expansion board.
5. Remove the PCI riser cage (Removing and replacing the PCI riser cage on page 153).
6. Disconnect any internal cables that are connected to the expansion board.
7. Remove the expansion board.
Removing and replacing a full-length expansion board 155
