The ORCA main menu contains the following options:
• Create Logical Drive
• View Logical Drive
• Delete Logical Drive
• Manage License Keys
Creating a logical drive
Procedure
1. At the ORCA main menu, select Create Logical Drive.
2. Select the physical disks to be included in the logical drive in the Available Physical Drives section.
3. To select the Raid Configurations section and select the RAID type for the logical drive, press Tab.
4. To select the Spare section and assign spare disks, as needed, press Tab.
5. To create the logical drive, press Enter. A summary of your choices appears.
6. To save the configuration, press F8.
7. If the function keys are disabled, press Esc and then press 8.
8. To acknowledge that the configuration was saved and return to the ORCA Main Menu, press Enter.
Deleting a logical drive
WARNING:
Back up all necessary data before deleting the logical drive. When you delete a logical drive, data
on the drive is not preserved.
Procedure
1. At the ORCA main menu, select Delete Logical Drive.
2. Select a logical drive to be deleted.
3. Press F3 to delete the logical drive.
4. If the function keys are disabled, press Esc and then press 3.
5. To acknowledge that the configuration was saved and return to the ORCA Main Menu, press Enter.
Adding a RAID Advanced Pack license key
Procedure
1. At the ORCA main menu, select Manage License Keys.
Creating a logical drive 185
