NOTE: After replacing the processor and heat sink module use the cpuconfig from UEFI to verify
the that the processor socket has been reconfigured.
Removing and replacing DIMMs
The server supports up to 24 memory DIMMs that attach to the system board through 4 memory
expansion board boards (6 DIMMs per board). The minimum amount of memory supported is 4 GB (two 2
GB DIMMs). The maximum memory supported is 384 GB (twenty-four 16 GB DIMMs). The supported
DIMMs are industry-standard, 30 mm (1.18 inch) high, DDR3 PC3 DIMMs. The server does not support
hot-spare and hot-plug functionality.
The server supports the following DIMM sizes:
• 2 GB
• 4 GB
• 8 GB
• 16 GB
For memory configurations see
Installing DIMMs.
Procedure
1. Power off the server (Powering off the server).
2. Extend or remove the server from the rack (Removing the server from the rack on page 139 or
Extending the server from the rack).
3. Remove the access panel (Removing the access panel).
4. Remove the memory expansion board.
164 Removing and replacing DIMMs
