Front panel LEDs
Table 14: Front panel controls
Name Function Status
UID button This button helps locate a particular server
within a rack of servers. You can remotely
activate this function through various system
utilities.
• Blue = Identification
• Flashing blue = Remote iLO session or a
firmware flash update is in progress
• Off = Off
System
health LED
This LED provides information about the
system status.
• Green = Health good on all internal FRUs
and system firmware has passed
"BOOT_START"
• Flashing Amber = A FRU or subsystem
has failed, or a fatal fault has occurred
(system is on or in standby mode).
• Flashing Red = A fatal fault has been
detected and a FRU or subsystem has
failed. View the SID, other LEDs, and the
logs for information.
• Off = Health good on all internal FRUs
and system off
NOTE:
The System Health LED does not
change status if AC power is removed
from a single power supply in a
rx2800 i2 server system with power
redundancy.
Power
button
This button manually powers the server on
and off.
• Green = System on
• Amber = System is powered off, but
standby power is on
• Off = System power and standby power
is off
The front panel of the system contains the power button/system power LED, health LED, System Event
Log LED, and locator switch/LED. The server use flashing states (for example, flashing amber or red) on
these LEDs to indicate a warning or an error.
There are a total of three LEDs, arranged vertically, with the UID button and the power button each having
an integrated LED. In addition to the two integrated button/LEDs, there is a health LED.
92 Front panel LEDs
