HPE Integrity rx2800 i2 series User Manual

Removing the system battery
For more information about battery replacement or proper disposal, contact an authorized reseller or an
authorized service provider.
Removing and replacing the SID
Procedure
1. Power off the server (Powering off the server).
2. Extend the server from the rack (Extending the server from the rack).
3. Remove the access panel (Removing the access panel).
4. Remove necessary fans 1 and 2.
5. Remove the screw securing the SID inside the chassis.
6. Disconnect the cable clip.
7. Pull the Systems Insight Display module halfway out of the server.
8. Disconnect the Systems Insight Display cable.
9. Remove the Systems Insight Display module.
Removing and replacing the SID 167
