Diagnostic
LEDs
Sample IPMI Events Cause Source Notes
I/O Card Type E0h, 133d:26d
IO_LBA_CLEAR_ERR_FAILED
I/O LBA clear error
failed
SFW
I/O Card Type E0h, 144d:26d
IO_SBA_CLEAR_ERR_FAILED
I/O SBA clear error
failed
SFW
I/O Card Type E0h, 146d:26d
IO_SLOT_POWER_ON_ERROR
PCI-X slot power on
error
SFW
I/O Card Type E0h, 145d:26d
IO_SLOT_POWER_DEFAULT_ERROR
PCI-X slot has
incorrect default
power state
SFW
I/O Card Type E0h, 136d:26d
IO_LBA_RESET_ERROR
I/O host bridge
(Lower Bus Adapter)
is inaccessible
because rope reset
failed to complete
SFW
I/O Card Type E0h, 130d:26d
IO_DLL_ERROR
PCI clock DLL error SFW
I/O Card Type E0h, 143d:26d
IO_ROPE_RESET_ERROR
I/O rope reset failed
to complete
SFW
I/O Card Type E0h, 7346d
CC_IODISC_LBA_LINK_TRAIN_ERR
PCIe link failed to
train
SFW
I/O Card Type E0h, 7356d
IO_PCIE_LINK_SUBOPTIMAL
PCIe link is not
running at max
capable bandwidth
SFW
Troubleshooting the iLO 3 MP subsystem
Cause
This subsection provides information on troubleshooting issues with the iLO 3 MP subsystem.
iLO 3 MP LAN LED on the rear panel
The iLO 3 MP LAN supports two LEDs, viewable from the rear of the system:
• iLO 3 LAN link LED, which indicates link speed
• iLO 3 LAN activity, which indicates link activity
Troubleshooting the iLO 3 MP subsystem 123
