Table 38: I/O card events that might illuminate SID LEDs
Diagnostic
LEDs
Sample IPMI Events Cause Source Notes
I/O Card Type E0h, 4658d:26d
IO_PCI_POWER_OVERLOAD_ERR
A non hot plug I/O
slot power
consumption
increases the total
I/O power
consumption beyond
the supported limit
SFW Disallow O/S
boot and
display the
following UEFI
error message,
"I/O
configuration
exceed"
I/O Card Type E0h, 137d:26d
IO_NOT_ENOUGH_POWER_ERROR
Insufficient power to
power on a hot-plug
PCI-X slot
SFW Display UEFI
warning
message
"Failed I/O
slots
deconfigured"
I/O Card Type E0h, 147d:26d
IO_SLOT_STANDBY_POWER_ERROR
PCI slot standby
power failed
SFW Either a card /
slot issue. Re-
seat card first.
I/O Card Type E0h, 131d:26d
IO_HOT_PLUG_CTRL_FAILED
PCI-X hot-plug
controller failed
SFW Either a card /
slot issue. Re-
seat card first.
I/O Card Type E0h, 139d:26d
IO_PCI_MAPPING_TOO_BIG
PCI bus walk (I/O
discovery) resources
exceeded
SFW Remove any
unsupported
I/O cards.
Move I/O card
to an unused
PCI slot
I/O Card Type E0h, 148d:26d
IO_UNKNOWN_PCIXCAP_VAL
Found invalid
PCIXCAP value
SFW
I/O Card Type E0h, 141d:26d
IO_PCIXCAP_SAMPLE_ERROR
PCIXCAP sampling
error
SFW
I/O Card Type E0h, 123d:26d
IO_CHECK_LBA_MISSING_ERR
Expected I/O host
bridge (Lower Bus
Adapter) is missing
SFW
I/O Card Type E0h, 619d:26d
IO_CHECK_LBA_DECONFIG_ERR
Expected I/O host
bridge (Lower Bus
Adapter) is
deconfigured
SFW
Table Continued
122 Troubleshooting
To Next Page
