To replace the component, reverse the removal procedure. When replacing the PCI riser cage, to ensure
that it has properly seated into the system board, push down on the top of the component where the riser
is located.
Removing expansion slot covers
CAUTION:
To prevent damage to the server or expansion boards, power off the server, and then remove all AC
power cords before removing or installing the PCI riser cage.
CAUTION:
For proper cooling, do not operate the server without the access panel, baffles, expansion slot
covers, or blanks installed. If the server supports hot-plug components, minimize the amount of time
the access panel is open.
Procedure
1. Remove the access panel (Removing the access panel on page 60).
2. Remove the PCI riser cage (Removing the PCI riser cage on page 60).
3. Remove the expansion slot cover.
a. To remove slot cover 1 or 4, push the retainer to release it, and then slide out the cover.
Removing expansion slot covers 61
