WARNING:
The ventilation holes in the pedestal kit right side piece
must
be matched up with the ventilation holes on the top cover of the rx2800 i2 server to enable proper
cooling and air flow. Failure to heed this warning causes the server to shut down with an overtemp
condition.
To attach the component:
Procedure
1. Align the posts on the pedestal kit right side piece with the slots in the pedestal kit top and bottom.
2. Hold the pedestal side flush against the server and slide it toward the front of the server.
Figure 11: Attaching the pedestal kit side piece
3. Secure the pedestal side by hand tightening the captive thumb screws on the rear of the server.
Installing the server 31
