To replace the component, reverse the removal procedure.
Removing and replacing the optical drive
Prerequisites
Before you perform this procedure, make sure that you have T-10 Torx screwdriver available.
Procedure
1.
If installed,
remove the bezel.
2.
Power down the server.
3.
Remove all power:
a.
Disconnect each power cord from the power source.
b.
Disconnect each power cord from the server.
4.
Disconnect all peripheral cables from the server.
5.
Remove the server from the rack.
6. Remove the inner rack rails.
7.
Remove the access panel.
8. Remove the optical drive:
• LFF
Removal and replacement procedures
78
