Step 2 Determine the rack number and chassis number of the server to be removed, and label its
panel to prevent misoperations.
Step 3 Power off the 5288 V3. For details, see 4.2 Powering Off the Server.
Step 4 Remove all external cables such as power and network cables.
Step 5 Remove the 5288 V3 and put it on an ESD desktop. For details, see 3.6 Removing the
Server.
Step 6 Remove the chassis cover. For details, see 7.11 Removing the Chassis Cover.
Step 7 Optional: (Optional) Open the two latches on the supercapacitor tray in their respective
directions, and remove the supercapacitor tray. See steps (1) and (2) in Figure 7-25.
Figure 7-25 Removing the supercapacitor tray
Step 8 Lift the air duct. See Figure 7-26.
Figure 7-26 Removing the air duct
5288 V3 Server
User Guide
7 Replacing Parts
Issue 26 (2018-11-19) Copyright © Huawei Technologies Co., Ltd. 141
