Figure 6-19 Removing the pump
Step 5 Open the fastener and remove two conversion connectors by using adjustable
wrench, as shown in Figure 6-20.
Figure 6-20 Removing the conversion connectors
When removing the hose, prepare a container for storing condensate because
some condensate may be drained.
Step 6 Open the sheet metals of the pump to drag the pump out.
Step 7 Install a new pump in an inverse order.
NetCol5000-A(025, 035) In-row Air Cooled Smart
Cooling Product
User Manual (600 mm Width) 6 System Operation and Maintenance
Issue 17 (2020-10-22) Copyright © Huawei Technologies Co., Ltd. 219
