Table 2-6 Installation requirements
Name Specications
Room The room can be sealed well.
Width ≥ 0.9 m; height ≥ 2.3 m.
Load bearing capacity ≥ 350 kg/m
2
; height of
underoor ≥ 250 mm.
Installation mode Installed on a concrete oor or an raised oor.
Pipe and cable
routing
Overhead or underoor piping and cabling bottom.
Self-drainpipe only supports underoor piping.
Length of one-way
refrigerant pipes
≤ 60 m.
Vertical distance
between indoor unit
and outdoor unit
● If the outdoor unit is placed higher than the indoor
unit, the maximum vertical distance between them is
20 m.
● If the indoor unit is placed higher than the outdoor
unit, the maximum vertical distance between them is
5 m.
Water Supply ● Water pressure ranges from 0.1 MPa to 0.7 MPa. (A
reducing valve must be installed if the inlet water
pressure exceeds 0.7 MPa.)
● Water temperature ranges from 1°C to 40°C.
● Transient ow is greater than or equal to 0.6 L/min.
● The quality of supplied water must meet the
requirements listed in Table 2-7.
Drain Water ● The upper drainage height of the condensate pump
should be 3.5 meters at most.
● Self-drainpipe inner diameter ≥ 19 mm, self-drainage
leveling tube length ≤ 2 m.
● The hose can be used in a environment whose
temperature is higher than 85°C. (The requirement is
only for the units with a
humidier.)
Power requirements ● 380–480 V 50 Hz or 60 Hz 3W+PE (Voltage jumpers
are used to conrm the rate voltage. The compatible
voltage jumpers include 380 V 50 Hz or 60 Hz, 400 V
50/60 Hz, 415 V 50 Hz or 60 Hz, 440 V 60 Hz, 460 V
60 Hz, and 480 V 60 Hz.)
● Tolerance: rated voltage ±10%; rated frequency ±3
Hz (Recommended to add a voltage regulator in the
front end if the power exceeds this range. Otherwise,
smart cooling product will generate frequency
alarms and cannot run.)
NetCol5000-A(025, 035) In-row Air Cooled Smart
Cooling Product
User Manual (600 mm Width) 2 Product Description
Issue 17 (2020-10-22) Copyright © Huawei Technologies Co., Ltd. 20
