sensor. Figure 3-51 shows the positions and cable routes for external humidity
and temperature sensors. The sensors can be secured to the cabinet using cable
ties or two M4 screws through sheet metal holes.
Figure 3-50 Position and cable route of an internal humidity and temperature
sensor
NetCol5000-A(025, 035) In-row Air Cooled Smart
Cooling Product
User Manual (600 mm Width) 3 Installation Guide
Issue 17 (2020-10-22) Copyright © Huawei Technologies Co., Ltd. 79
