● RS485_R must be switched to OFF.
● After the address is set, choose Settings > System Settings > T/H Sensor on
the home page after power-on and set the sensors in the aisle corresponding to
the address to Enable. Otherwise, the sensors will not work.
Table 3-17 DIP switch operation description
Position Name Address DIP Switch ID
1 2 3 4 5 6
Return
air side
Temperature
and humidity
1 at the
return air
vent
1 ON OFF OFF OFF OFF OFF
Cold
aisle
Temperature
and humidity
1 at the cold
aisle
11 ON ON OFF ON OFF OFF
Temperature
and humidity
2 at the cold
aisle
12 OFF OFF ON ON OFF OFF
Temperature
and humidity
3 of the cold
aisle
13 ON OFF ON ON OFF OFF
Hot
aisle
Temperature
and humidity
1 at the hot
aisle
21 ON OFF ON OFF ON OFF
Temperature
and humidity
2 at the hot
aisle
22 OFF ON ON OFF ON OFF
Temperature
and humidity
3 at the hot
aisle
23 ON ON ON OFF ON OFF
NetCol5000-A(025, 035) In-row Air Cooled Smart
Cooling Product
User Manual (600 mm Width) 3 Installation Guide
Issue 17 (2020-10-22) Copyright © Huawei Technologies Co., Ltd. 81
