Huawei SmartAX MA5608T Hardware Description

Figure 2-30 Configuration of boards in the MA5608T chassis (with H801MPWE power
board)
FAN
0
1
2
GPIO
Service board
3
4
5
Service board
Control board
Control board
Power
board
Power
board
Table 2-45 lists the configuration of boards in the MA5608T chassis. For details, see 3.5
Board Configuration(MA5608T).
Table 2-45 Boards in the MA5608T chassis
Slot Type
Slot Supported Board Remarks
Control board
slot
2, 3 Control board Two slots must be configured
with the same control board.
You are advised to configure 2
control boards working in
active/standby mode.
Power board
slot
4 H801MPWC,
H801MPWD power
board
-
4, 5 H801MPWE power
board
-
Service board
slot
0, 1 Service board
l SPU board
l Ethernet service
access board
l TDM service
processing board
l GPON service board
l 10G GPON service
board
l P2P interface board
l ATM interface board
l Combo board
l Voice board
l ADSL2+ service
board
l VDSL2 service board
l SHDSL service board
Mixed configuration of service
boards is supported.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
2 Subrack and Chassis
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
135

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
