Indicator
Indicato
r
Name Color Status Meaning
RUN
ALM
Running
status
indicator
Green Blinking The board functions
properly
Red Blinking The board is starting up
Orange Blinking
(supported in
V800R009C00 and
later versions)
A high-temperature alarm
is generated
Red On The board is faulty
ACT Active
indicator
Green On In active/standby mode,
the board is active
- Off In active/standby mode,
the board is standby
Daughter Board
The H801SCUL board can be configured with a matching daughter board. Figure 3-15 shows
the position of the daughter board on the H801SCUL board.
For details about the daughter board and functions supports by the H801SCUL board, see
3.6.11 Daughter Board..
