Indicator
Indicato
r
Name Color Status Meaning
RUN
ALM
Running
status
indicator
Green Blinking slowly (on
for 1 s and off for 1 s
repeatedly)
The board works in the
normal state
Green Blinking quickly (on
for 0.25 s and off for
0.25 s repeatedly)
The board is
communicating with the
control board
Red Blinking The board is in the APP
startup phase
Orange Blinking A high-temperature alarm
is generated
Red On The board is faulty
BSY Port status
indicator
Green On At least one service port is
activated
- Off No service port is
activated
Daughter Board
The H802DSRE board supports a daughter board port, which can be installed with the
H806DSDB daughter board.
Figure 3-98 shows the position of the daughter board on the H802DSRE board.
