Figure 3-98 Position of the daughter board on the H802DSRE board
subboard
Table 3-73 describes the daughter board supported by the H802DSRE board.
Table 3-73 Daughter board supported by the H802DSRE board
Daughter board
Function Remarks
H806DSDB Supports the VoIP function. Mandatory
Pin Assignments
Table 3-74 describes the pin assignments of the LINE port on the front panel of the
H802DSRE board.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
3 Board
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
504
