Huawei SmartAX MA5608T Hardware Description

Table 3-149 Vectoring Hardware
Product Board
Type
Board
Name
Remarks Correspondin
g Outdoor
Cabinet
Terminals
MA5603T Control
board
SCUB
SCUN
SCUH
SCUK
Supports SLV
only.
S300/T300/
T500
Vectoring can
be implemented
on VDSL2 lines
only when their
connected
terminals
support
vectoring.
Vectoring-
supported
Huawei
terminals
include the
HG612,
HG622,
HG630, and
HG658. For
details about the
version of these
terminals in
supporting
vectoring, see
the product
documents of
these terminals.
Backpla
ne
H802M
ABO
None
VP
board
H806V
PEA
H806V
PEF
Installed in slot
12 fixedly.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
3 Board
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
720

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
