Huawei SmartAX MA5608T Hardware Description

Product Board
Type
Board
Name
Remarks Correspondin
g Outdoor
Cabinet
Terminals
VDSL2
board
l H80
BV
CM
M
l H80
DC
CPE
l H80
DV
CPD
l H80
DV
CPE
l H80
DV
CP
M
l H80
DSD
MM
l
The
H80BVCM
M board is a
48-channel
VDSL2 over
POTS access
service
board.
l The
H80DCCPE
board is a
64-channel
VDSL2&PO
TS Combo
Board with
built-in
splitter.
l The
H80DVCPD
board is a
64-channel
VDSL2 over
POTS access
service
board.
l The
H80DVCPE
board is a
64-channel
VDSL2 over
POTS access
service
board,
equipped
with a built-
in splitter.
l The
H80DVCP
M board is a
64-channel
VDSL2 over
POTS access
service
board.
l H80DSDM
M: 48-
channel
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
3 Board
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
721

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
