Huawei SmartAX MA5608T Hardware Description

Product Board
Type
Board
Name
Remarks Correspondin
g Outdoor
Cabinet
Terminals
MA5623A
R
N/A N/A The
MA5623AR
extended
subrack can be
considered as
the extension
service board
for the main
subrack. The
main subrack
manages the
MA5623AR
extended
subrack in the
same way as it
manages its
service boards.
The
MA5623AR
extended
subrack
provides the
same functions
as the VDSL2
board of the
main subrack.
N/A
MA5616 Control
board
H831C
CUE
Supports SLV
and NLV.
S200/S100
Daughte
r board
UP2CA
/
UP2AA
None
Backpla
ne
H831M
ABB
None
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
3 Board
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
724

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
