Huawei SmartAX MA5608T Hardware Description

Product Board
Type
Board
Name
Remarks Correspondin
g Outdoor
Cabinet
Terminals
VP
board
H836V
PBA
H836V
PDA
H836V
PME
l H836VPBA/
H836VPME
: A daughter
board for
SLV;
attached to
the power
board.
l H836VPDA:
A daughter
board for
NLV;
attached to
the power
board. It
only can be
used
together
with
H83BVCM
M,
H83BVCLE
or
H83BVCLF
board for
vectoring.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
3 Board
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
725

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
