Huawei SmartAX MA5608T Hardware Description

Product Board
Type
Board
Name
Remarks Correspondin
g Outdoor
Cabinet
Terminals
VDSL2
board
H83BV
CMM
H83DV
CMM
H83BV
CLE
H83BV
CLF
H83DC
CME
H83DS
DMM
l H83BVCM
M/
H83DVCM
M: 48-
channel
VDSL2
access
service
board.
l H83BVCLE
/
H83BVCLF:
32-channel
VDSL2
access
service
board.
l H83DCCM
E: 48-
channel
VDSL2&PO
TS combo
board.
l H83DSDM
M: 48-
channel
SuperVector
access
service
board.
Power
board
H831P
AVDA
H832P
DVAA
H832P
DNAA
H832P
DMSB
l H831PAVD
A: An AC
power board
for SLV.
l H832PDVA
A: A DC
power board
for SLV.
l H832PDNA
A: A DC
power board
for NLV.
l H832PDMS
B: A DC
power board
for SLV.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
3 Board
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
726

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
